The DCE 5201A-BM ADSL2+ Bridge Modem is a single port Ethernet ADSL2/2+ Bridge Modem that connects an "Always-On" high-speed Asymmetric Digital Subscriber Line (ADSL) connection, to a single 10/100BASE-T Ethernet port connection for a PC or other Ethernet device to enable Internet connectivity.

The DCE/5201A-BM Bridge/Modem enables the user to have a single public IP address (or multiple) pass seamlessly through to your router or firewall.

TheDCE 5201A-BM supports TR-069 and it works with most TR-069-based central management systems.

DCE's DCE/5201A-BM is fully compliant with ADSL, ADSL2, ADSL2+, Annex M and RE-ADSL2/2+ specifications. This rate-adaptive solution is especially designed for enterprise, telecommuters, home or SOHO users, supporting ADSL2/2+ downstream and upstream data rates of up to 24Mbps downstream, and 2.5Mbps upstream.

DCE 5201A-BM Features

• Compact design for home office, small office and residential users
• Compliant to the most updated ADSL2/2+ standards
• Supports ADSL2+ downstream data rate of up to 24Mbps
• RFC 1483 Bridge
• Hardware Reset button for fast default setting recovery
• Interoperable with all major DSLAMs
• Ideal for SOHO and Home User
• Auto Quick-Detect most popular VPI/VCI settings

• ANSI T1.413 i2, G.992.1 and G.992.2 ADSL standard compliant
• G.992.3 and G.992.5 ADSL2 and ADSL2+ standard compliant
• Downstream/Upstream data rate up to 24Mbps / 2.5Mbps with Annex M

• Supports up to 8 distinct PVCs
• Supports VC and LLC Multiplexing
• Supports UBR, CBR, VBR-rt and VBR-nrt Traffic Shaping QoS
• Supports hardware ATM AAL0 and AAL5 adaptation functionality
• Supports F4/F5 OAM Cells

• RFC2684 (RFC1483) – Bridged
• Supports IEEE 802.1d Transparent Bridging
• Supports RIP v1 and v2 *
• Supports DHCP Server/Client/Relay *
• Supports DNS Proxy *
• Supports IGMP Proxy *
• Supports Port Mapping/Forwarding *
• Supports Port Triggering *

• Supports IP Filtering *
• Supports Port Filtering *
• Supports DMZ *
• Supports MAC/Bridge Filtering *
• Supports URL Blocking *
• Embedded firewall functionality *

• Supports IP QoS *
• Web-based Control/Management *
• Remote Access Control *
• Remote Telnet *
• SNMP v2 (Support TRAP) *
• ATM PVC Remote Management *
• Firmware upgrade via HTTP/TFTP/FTP *
• Built-in diagnostic function *
• System Log *
• TR-69 support with 2M16M *

   * Available in Routed Mode.  If you need any of these features please take a look at the DCE/5201A-MR.
