 The DrayTek Vigor2910V Dual WAN Broadband Security Router features true Plug and play installation. Just connect your cable or DSL Ethernet modem and PC to the router and you're online. All configuration is achieved using the Vigor 2910Vs' web based interface; this can be performed from a wired or wireless PC on the network using a standard web browser.
Features
Here are just a few reasons why you should buy the DrayTek Vigor 2910V Vigorus Broadband Security Router today!
- Multi-port cable router, ideal for creating a secure network with a shared Internet access
- Suitable for use with any cable or DSL ethernet modem - plug and play install
- Built in VPN server - dial into the router using a VPN client and access your network remotely
- Integrated USB print server - share your USB printer over the network without needing to leave a host PC
switched on (requires uni-directional printer)
- Built in Super G 108Mbps wireless access point
- See Datasheet for technical specifications
NOTE: This product does not incorporate a built-in modem. To use this product you will need either a
Cable Modem or DSL Ethernet Modem.
Quick Spec's
Dual-WAN
- Outbound Policy-Based Load-Balance
- BoD (Bandwidth on Demand)
- WAN Connection Fail-over
VoIP
- Protocol: SIP, RTP / RTCP
- Six SIP Registrars
- G.168 Line Echo-Cancellation
- Automatic Gain Control
- Jitter Buffer (125ms)
- Codec Feature:
- G.711 A/µ Law
- G.723.1
- G.726
- G.729 A/B
- VAD / CNG
- Tone Generation and Detection : DTMF, Dial, Busy, Ring Back, Call Progress
- FAX / Modem Suport :
- G.711 Pass-through
- T.38 for FAX
- Supplemental Services
- Call Hold / Retrieve
- Call Waiting
- Call Transfer
- Call Forwarding ( Always, Busy and No Answer )
- DND ( Do not Disturb )
- Hotline
WAN Protocol
- DHCP Client
- Static IP
- PPPoE
- PPTP
- BPA
- L2TP *
Firewall
- CSM (Content Security Management) for IM/P2P Application
- Multi-NAT, DMZ Host, Port-Redirection/Open Port
- Policy-Based IP Packet Filter
- DoS/DDoS Protection
- IP Address Anti-Spoofing
- E-Mail Alert and logging via Syslog
- Bind IP to MAC Address
VPN
- Up to 32 VPN Tunnels
- Protocol: PPTP, IPSec, L2TP, L2TP over IPSec
- Encryption: AES, MPPE and Hardware-Based DES/3DES
- Authentication: MD5, SHA-1
- IKE Authentication: Pre-shared Key and Digital Signature (X.509)
- LAN-to-LAN, Teleworker-to-LAN
- DHCP over IPSec
- NAT-Traversal (NAT-T)
- Dead Peer Detection (DPD)
- VPN Pass-Through
Bandwidth Management
- Class-based Bandwidth Guarantee by User-Defined Traffic Categories
- DiffServ Code Point Classifying
- 4-level Priority for Each Direction (Inbound/Outbound)
- Bandwidth Borrowed
- Bandwidth/Session Limitation
Network Management
- Web-Based User Interface (HTTP/HTTPS)
- Quick Start Wizard
- CLI (Command Line Interface) / Telnet/SSH*
- Administration Access Control
- Configuration Backup/Restore
- Built-in Diagnostic Function
- Firmware Upgrade via TFTP/FTP
- Logging via Syslog
- SNMP Management with MIB-II
Content Filter
- URL Keyword Blocking (White list and Block list)
- Java Applet, Cookies, Active X, Compressed / Executable / Multimedia File Blocking
- Web Content Filter (SurfControl)
- Time Schedule Control
Network Features
- DHCP Client/Relay/Server
- Dynamic DNS
- NTP Client
- Call Scheduling
- RADIUS Client
- DNS Cache/Proxy
- UPnP
- Prot-Based VLAN
- Configurable WAN2
- Routing Protocol
- Static Routing
- RIP V2
